Highsider 5 3/4 "LED Headlight Atlanta 223-001

Highsider Atlanta Headlight 5 3/4 Inch Led with parking light, metal house, side mounting, e-homologated.

The Innovation for Your Safety - The Model Atlanta is a headlight equipped with 4 power led, which is available in the following variants: in a high quality black metal house with black insert or in a high quality chrome plated metal house. The Led Technology for Low Beam and High Beam Produces A Symmetrical, Daylight-like Light for Optimal Visibility, E-Approved.

The Bright Joy: give your bike an unmistakable style! The Fancy Design and the Perfect Technology of the Highsider Headlight Series Make You An Eye-Catching Highlight in any case.

Headlight Dimensions:

• Diameter: 145 mm
• Depth: 95 mm (From Fixing Screw To Realar Housing)
• Depth: 135 mm

Control Box Dimensions:

• Height: 74 mm
• Width: 42 mm
• Depth: 21 mm

Fixing: Lateral with Fixing Screws M6

Weights:

• Headlight approx. 1200 g
• Control part approx. 210 g

Technical Data:

• Power Consumption Low Beam AT 12.5 VOLTS: 1.1 Amperes (13.75 Watts)
• Power Consumption High Beam AT 12.5 VOLTS: 2.3 AMPERES (28.75 watts)
• Luminous flux at 12 volts: high and low beams of 1200 lumens each

Connections:

• 9 -16 volts DC
• Black = ground
• White Cable = Low Beam
• Blue Cable = High Beam
• Brown Cable = Parking Light

SUPPLIED WITH: 1 Piece

Note: The Control Box must be connected!
